FITTING A197

FITTING A197

JUAL VALVE MERK SANKO

JUAL VALVE MERK SANKO

JUAL GATE VALVE SANKO ANSI #150 #300
MATERIAL STANDARD :
ASTM A216 WCB
BASIC DESIGN : API 600 ASME B16.34
FACE TO FACE : ASME B16.10
FLANGE END : ASME B16.5
TEST AND INSPECTION : API 598

JUAL CHECK VALVE SANKO ANSI #150 #300
MATERIAL STANDARD :
ASTM A216 WCB
BASIC DESIGN : API 600 ASME B16.34
FACE TO FACE : ASME B16.10
FLANGE END : ASME B16.5
TEST AND INSPECTION : API 598

JUAL YSTRAINER SANKO ANSI #150 #300
MATERIAL STANDARD :
ASTM A216 WCB
BASIC DESIGN : API 600 ASME B16.34
FACE TO FACE : ASME B16.10
FLANGE END : ASME B16.5
TEST AND INSPECTION : API 598

JUAL BALL VALVE SANKO ANSI #150 #300
MATERIAL STANDARD :
ASTM A216 WCB
BASIC DESIGN : API 600 ASME B16.34
FACE TO FACE : ASME B16.10
FLANGE END : ASME B16.5
TEST AND INSPECTION : API 598


All the items we sell at competitive rates,
and our customers a lot of big cities in Indonesia
If in doubt, we can provide our customers on where you are!

Please contact our marketing for more details ( Klik )

HARGA GATE VALVE PN.10 PN.16.PN.40

Jual Macam Macam Gate Valve Sbb :

Tersedia bahan :
Carbon Steel ASTM A216 WCB
Stainless Steel A351-CF8 / CF8M
Cast Iron JIS F 7373:1996
Ductile Iron DIN 3356-2
Bronze

Standard Koneksi :
Flange : Class #150 - #300
Flange : Jis 10K - 16K
Flange : PN.16 - 40
Screw / NPT















JUAL ANGLE VALVE BRASS 5K

HARGA ANGLE VALVE BRASS 5K  MARINE | HARGA GLOBE VALVE BRASS 5K



TAGS :
ANGLE VALVE | GATE VALVE | BALL VALVE | CHECK VALVE | Y STRAINER | CONTROL VALVE | PRESURE REDUCING VALVE | STEAM TRAP | SOLENOID VALVE | WATER HAMMER | GLOBE VALVE | BUTTERFLY VALVE | SAFETY VALVE | AIR VENT VALVE | TUSEN KLEP | KNIFE GATE VALVE | ORIFICE AIR VALVE | SIGHT GLASS VALVE

JUAL GLOBE VALVE BRASS UNTUK MARINE

HARGA ANGLE VALVE BRASS 5K  | HARGA GLOBE VALVE BRASS 5K


TAGS :
ANGLE VALVE | GATE VALVE | BALL VALVE | CHECK VALVE | Y STRAINER | CONTROL VALVE | PRESURE REDUCING VALVE | STEAM TRAP | SOLENOID VALVE | WATER HAMMER | GLOBE VALVE | BUTTERFLY VALVE | SAFETY VALVE | AIR VENT VALVE | TUSEN KLEP | KNIFE GATE VALVE | ORIFICE AIR VALVE | SIGHT GLASS VALVE

HARGA FLANGE SS304 STAINLESS STEEL

Selain menjual flange PN40 RF C/S kami juga menjual flange :

Jual flange PN16, jual flange PN10, jual flange PN16 besi, jual flange PN10 stainless, jual flange 10k ns, jual flange carbon steel ss400, jual flange stainless steel, jual flange merk ulma, jual flange slip on, jual flange merk shinsei,  jual flange buta, jual flange merk cina,  jual flange wn, jual flange merk metal far,  jual flange ansi,  jual flange jis,  jual flange pn dll

HARGA FLANGE SS304 PN.10 RF
SIZEHARGA
1/2"79.000
3/4"CALL
1"CALL
1-1/4"CALL
1-1/2"CALL
2"CALL
2-1/2"CALL
3"CALL
4"CALL
5"CALL
6"CALL
8"CALL
10"CALL
12"CALL
14"CALL
16"CALL
18"CALL
20"CALL
22"CALL
24"CALL


All the items we sell at competitive rates,
and our customers a lot of big cities in Indonesia
If in doubt, we can provide our customers on where you are!

Please contact our marketing for more details ( Klik )

JUAL STUD BOLT FLUOROCARBON COATING

JUAL STUD BOLT B7 CW NUT 2H FLUOROCARBON COATING
Sebagian besar Perusahaan menyadari bahwa pemeliharaan adalah masalah besar Terutama untuk baut pengencang flange, valve dan lain lain.
Untuk memperpanjang umur stud bolt itu sendiri terciptalah stud bolt yang di lapisi Xylan Fluorocarbon PTFE sebagai penghalang korosi yang sangat baik, meski diaplikasikan sekitar 25 mikron, lapisan ini mampu mengurangi korosi parah yang mempengaruhi stud bolt dan nut pada pengeboran minyak lepas pantai, kilang dan peralatan pengolahan petrokimia, serta barang-barang lainnya yang terkait dengan industri pengolahan kimia.
Dengan Lapisan ini juga memungkinkan penggunaan stud bolt yang lebih murah & lebih kuat dari stainless steel & bahan lain yang lebih mahal.
Stud bolt berlapis Xylan Fluorocarbon PTFE datang dalam banyak warna dan rentang warna populer dari Dark Yellow sampai hitam dengan Reds and Blues dan hijau menjadi yang paling luas di pasar dunia.

JUAL STUD BOLT FLUOROCARBON COATING
JUAL STUD BOLT FLUOROCARBON COATING
Keuntungan dan kelebihan dari Lapisan Fluorocarbon PTFE :
✔ ketahanan suhu tinggi
✔ Efisiensi gesek yang rendah
✔ Tahan korosi
✔ ketahanan kimia
✔ Mudah perakitan & pelepasan

PTFE Coating Statistics
Tensile Strength (ASTM D1708) 3000-5000 psi
Elongation (ASTM D1457) 300-500%
Impact Strength (ASTM D256) 3.5 ft-LB/in
Hardness (ASTM D2240) 50-65 HB (shore D)
Abrasion Resistance (Tabor) 12 mg
Coefficient of Friction (ASTM D1894) .12 -.15 static, .05 -.10 dynamic
Dielectric Strength (ASTM D149) 450 volts per mil
Use Temperature 600°F max
Melting Point 625°F
Thermal Conductivity 1.7 BTU-in/h-ft 2-°F
Chemical Resistance (ASTM D543) Excellent
Salt Spray Resistance (ASTM B117) Fair
Water Absorption (ASTM D570) -
Thickness .001" - .003"

STUD BOLT FLUOROCARBON

A193 Grades For Stud Bolt
B7 Alloy steel, AISI 4140/4142 quenched and tempered
B8 Class 1 Stainless steel, AISI 304, carbide solution treated.
B8M Class 1 Stainless steel, AISI 316, carbide solution treated.
B8 Class 2 Stainless steel, AISI 304, carbide solution treated, strain hardened
B8M Class 2 Stainless steel, AISI 316, carbide solution treated, strain hardened

A193 Chemical Properties For Stud Bolt
ElementB7 (AISI 4140)B8 (AISI 304)B8M (AISI 316)
Carbon 0.37 - 0.49% 0.08% max 0.08% max
Manganese 0.65 - 1.10% 2.00% max 2.00% max
Phosphorus, max 0.035% 0.045% 0.045%
Sulfur, max 0.040% 0.030% 0.030%
Silicon 0.15 - 0.35% 1.00% max 1.00% max
Chromium 0.75 - 1.20% 18.0 - 20.0% 16.0 - 18.0%
Nickel 8.0 - 11.0% 10.0 - 14.0%
Molybdenum 0.15 - 0.25% 2.00 - 3.00%

NUT 2H FLUOROCARBON PTFE
A194 Grades For Nut
2 Carbon steelheavy hex nuts
2H Quenched & tempered carbon steel heavy hex nuts
2HM Quenched & tempered carbon steel heavy hex nuts, 100% hardness tested
4 Quenched & tempered carbon-molybdenum heavy hex nuts (withdrawn in 2017)
7 Quenched & tempered alloy steel heavy hex nuts
7M Quenched & tempered alloy steel heavy hex nuts, 100% hardness tested
7L Quenched & tempered alloy steel heavy hex nuts, Charpy impact tested
8 Stainless AISI 304 heavy hex nuts
8M Stainless AISI 316 heavy hex nuts

A194 Chemical Properties For Nut
Element2, 2H, and 2HM47 and 7M (AISI 4140)8 (AISI 304)8M (AISI 316)
Carbon 0.40% min 0.40 - 0.50% 0.37 - 0.49% 0.08% max 0.08% max
Manganese 1.00% max 0.70 - 0.90% 0.65 - 1.10% 2.00% max 2.00% max
Phosphorus, max 0.040% 0.035% 0.035% 0.045% 0.045%
Sulfur, max 0.050% 0.040% 0.040% 0.030% 0.030%
Silicon 0.40% max 0.15 - 0.35% 0.15 - 0.35% 1.00% max 1.00% max
Chromium 0.75 - 1.20% 18.0 - 20.0% 16.0 - 18.0%
Nickel 8.0 - 11.0% 10.0 - 14.0%
Molybdenum 0.20 - 0.30% 0.15 - 0.25% 2.00 - 3.00%

DIAMETER DAN PANJANG STUD BOLT UNTUK FLANGE ANSI

DIAMETER DAN PANJANG STUD BOLT UNTUK FLANGE ANSI

Jumlah Stud bolt, diameter dan panjang untuk flange ANSI class 150 lb, 300 lb, 400 lb, 600 lb, 900 lb dan 1500 lb dapat ditemukan pada tabel di bawah ini.
Bagan tersebut untuk tampilan standar dan tingkat tekanan standar mengarah ke flange sesuai dengan ANSI / ASME B16.5.
DIAMETER DAN PANJANG STUD BOLT UNTUK FLANGE ANSI
Stud Bolt Flange
FLANGE ANSI / ASME B16.5. - CLASS 150 RAISED FACE ( RF )
NPS(in)No. ofStudsDiameter of Stud(in)Length of Stud(in)
1/2 4 1/2 2-1/2
3/4 4 1/2 2-1/2
1 4 1/2 2-3/4
1-1/4 4 1/2 2-3/4
1-1/2 4 1/2 3
2 4 5/8 3-1/2
2-1/2 4 5/8 3-3/4
3 4 5/8 3-3/4
3-1/2 8 5/8 3-3/4
4 8 5/8 3-3/4
5 8 3/4 4
6 8 3/4 4-1/4
8 8 3/4 4-1/2
10 12 7/8 4-3/4
12 12 7/8 5
14 12 1 5-1/2
16 16 1 5-1/2
18 16 1-1/8 6
20 20 1-1/8 6-1/2
24 20 1-1/4 7

FLANGE ANSI / ASME B16.5. - CLASS 300 RAISED FACE ( RF )
NPS(in)No. ofStudsDiameter of Stud(in)Length of Stud(in)
1/2 4 1/2 2-3/4
3/4 4 5/8 3-1/4
1 4 5/8 3-1/4
1-1/4 4 5/8 3-1/2
1-1/2 4 3/4 3-3/4
2 8 5/8 3-3/4
2-1/2 8 3/4 4-1/4
3 8 3/4 4-1/2
3-1/2 8 3/4 4-1/2
4 8 3/4 4-3/4
5 8 3/4 5
6 12 3/4 5
8 12 7/8 5-3/4
10 16 1 6-1/2
12 16 1-1/8 7
14 20 1-1/8 7-1/4
16 20 1-1/4 7-3/4
18 24 1-1/4 8
20 24 1-1/4 8-1/4
24 24 1-1/2 9-1/4

FLANGE ANSI / ASME B16.5. - CLASS 400 RAISED FACE ( RF )
NPS(in)No. ofStudsDiameter of Stud(in)Length of Stud(in)
1/2 4 1/2 3-1/4
3/4 4 5/8 3-3/4
1 4 5/8 3-3/4
1-1/4 4 5/8 4
1-1/2 4 3/4 4-1/2
2 8 5/8 4-1/2
2-1/2 8 3/4 5
3 8 3/4 5-1/4
3-1/2 8 7/8 5-3/4
4 8 7/8 5-3/4
5 8 7/8 6
6 12 7/8 6-1/4
8 12 1 7
10 16 1-1/8 7-3/4
12 16 1-1/4 8-1/4
14 20 1-1/4 8-1/2
16 20 1-3/8 9
18 24 1-3/8 9-1/4
20 24 1-1/2 9-3/4
24 24 1-3/4 10-3/4

FLANGE ANSI / ASME B16.5. - CLASS 600 RAISED FACE ( RF )
NPS(in)No. ofStudsDiameter of Stud(in)Length of Stud(in)
1/2 4 1/2 3-1/4
3/4 4 5/8 3-3/4
1 4 5/8 3-3/4
1-1/4 4 5/8 4
1-1/2 4 3/4 4-1/2
2 8 5/8 4-1/2
2-1/2 8 3/4 5
3 8 3/4 5-1/4
3-1/2 8 7/8 5-3/4
4 8 7/8 6
5 8 1 6-3/4
6 12 1 7
8 12 1-1/8 7-3/4
10 16 1-1/4 8-3/4
12 20 1-1/4 9
14 20 1-3/8 9-1/2
16 20 1-1/2 10-1/4
18 20 1-5/8 11
20 24 1-5/8 11-1/2
24 24 1-7/8 13

FLANGE ANSI / ASME B16.5. - CLASS 900 RAISED FACE ( RF )
NPS(in)No. ofStudsDiameter of Stud(in)Length of Stud(in)
1/2 4 3/4 4-1/2
3/4 4 3/4 4-3/4
1 4 7/8 5-1/4
1-1/4 4 7/8 5-1/4
1-1/2 4 1 5-3/4
2 8 7/8 6
2-1/2 8 1 6-1/2
3 8 7/8 6
4 8 1-1/8 7
5 8 1-1/4 7-3/4
6 12 1-1/8 7-3/4
8 12 1-3/8 9
10 16 1-3/8 9-1/2
12 20 1-3/8 10-1/4
14 20 1-1/2 11
16 20 1-5/8 11-1/2
18 20 1-7/8 13
20 20 2 14
24 20 2-1/2 17-1/2

FLANGE ANSI / ASME B16.5. - CLASS 1500 RAISED FACE ( RF )
NPS(in)No. ofStudsDiameter of Stud(in)Length of Stud(in)
1/2 4 3/4 4-1/2
3/4 4 3/4 4-3/4
1 4 7/8 5-1/4
1-1/4 4 7/8 5-1/4
1-1/2 4 1 5-3/4
2 8 7/8 6
2-1/2 8 1 6-1/2
3 8 1-1/8 7-1/4
4 8 1-1/4 8
5 8 1-1/2 10
6 12 1-3/8 10-1/2
8 12 1-5/8 11-3/4
10 12 1-7/8 13-1/2
12 16 2 15
14 16 2-1/4 16-1/2
16 16 2-1/2 18
18 16 2-3/4 19-1/2
20 16 3 21-1/2
24 16 3-1/2 24-1/2
Note :
Jika terdapat hitungan panjang stud bolt dengan mm hitungan sederhananya seperti contoh di bawah ini :

1 inch is equal to 25.4 millimeters:
1″ = 25.4mm

Contoh :
Konversi 20 inch ke millimeters:
d(mm) = 20″ × 25.4 = 508mm

Konversi 203.2 millimeters ke inch :
d(mm) = 203.2 : 25.4 = 8" Inch

Konversi table Inch ke millimeters
Inche (")Millimeters (mm)
0.01" 0.254000 mm
1/64" 0.396875 mm
1/32" 0.793750 mm
1/16" 1.587500 mm
0.1" 2.540000 mm
1/8" 3.175 mm
1/4" 6.35 mm
1/2" 12.7 mm
1" 25.4 mm
2" 50.8 mm
3" 76.2 mm
4" 101.6 mm
5" 127.0 mm
6" 152.4 mm
7" 177.8 mm
8" 203.2 mm
9" 228.6 mm
10" 254.0 mm
20" 508.0 mm
30" 762.0 mm
40" 1016.0 mm
50" 1270.0 mm
60" 1524.0 mm
70" 1778.0 mm
80" 2032.0 mm
90" 2286.0 mm
100" 2540.0 mm

Jika info ini bermanfaat silahkan klik dan Share

STUD BOLTS CHEMICAL ANALYSIS

Awalnya disetujui pada tahun 1936, spesifikasi ini banyak digunakan dalam aplikasi konstruksi perminyakan dan kimia. Standar ASTM mencakup baja paduan dan baja tahan karat bahan untuk suhu tinggi atau layanan tekanan tinggi. Spesifikasi ini mencakup pengencang yang ditujukan untuk digunakan pada bejana tekan, katup, flensa, dan alat kelengkapan. Meskipun, bahan ini sering tersedia dalam lempeng benang kasar nasional (UNC), jika digunakan dalam aplikasi tradisional, benang ditentukan 8 benang per inci (tpi) untuk diameter di atas satu inci. Berikut adalah ringkasan dasar beberapa nilai umum. ASTM A193 mencakup sejumlah spesifikasi standar lainnya yang tidak tercakup dalam uraian ini termasuk B5, B6, dan B16.

STUD BOLTS CHEMICAL ANALYSIS

A193 Grades
B7 Alloy steel, AISI 4140/4142 quenched and tempered
B8 Class 1 Stainless steel, AISI 304, carbide solution treated.
B8M Class 1 Stainless steel, AISI 316, carbide solution treated.
B8 Class 2 Stainless steel, AISI 304, carbide solution treated, strain hardened
B8M Class 2 Stainless steel, AISI 316, carbide solution treated, strain hardened


A193 Mechanical Properties
GradeSizeTensile ksi, minYield, ksi, minElong, %, minRA % minHBWHRC
B7 Up to 2-1/2 125 105 16 50 321 max 35 max
2-5/8 - 4 115 95 16 50
4-1/8 - 7 100 75 18 50
B8 Class 1 All 75 30 30 50 223 max 35 max
B8M Class 1 All 75 30 30 50 223 max 96 max
B8 Class 2 Up to 3/4 125 100 12 35 321 max 35 max
7/8 - 1 115 80 15 35
1-1/8 - 1-1/4 105 65 20 35
1-3/8 - 1-1/2 100 50 28 45
B8M Class 2 Up to 3/4 110 95 15 45 321 max 35 max
7/8 - 1 100 80 20 45
1-1/8 - 1-1/4 95 65 25 45
1-3/8 - 1-1/2 90 50 30 45


A193 Chemical Properties
ElementB7 (AISI 4140)B8 (AISI 304)B8M (AISI 316)
Carbon 0.37 - 0.49% 0.08% max 0.08% max
Manganese 0.65 - 1.10% 2.00% max 2.00% max
Phosphorus, max 0.035% 0.045% 0.045%
Sulfur, max 0.040% 0.030% 0.030%
Silicon 0.15 - 0.35% 1.00% max 1.00% max
Chromium 0.75 - 1.20% 18.0 - 20.0% 16.0 - 18.0%
Nickel 8.0 - 11.0% 10.0 - 14.0%
Molybdenum 0.15 - 0.25% 2.00 - 3.00%


A193 Recommended Hardware
Bolt GradeNutsWashers
B7 A194 Grade 2H F436
B8 Class 1 A194 Grade 8 SS304
B8M Class 1 A194 Grade 8M SS316
B8 Class 2 A194 Grade 8 SS304
B8M Class 2 A194 Grade 8M SS316

Grades of Stud Bolts
Below a table with materials and grades for flanges, recommended.
DESIGNTEMP. FLANGES GRADETHREAD RODS GRADE NUTS
-195° to 102°C ASTM A182Gr. F304, F304L, F316,F316L, F321, F347 A320 Gr.B8 Class2 A194 Gr.8A
-101° to -47°C ASTM A350Gr.LF3 A320 Gr.L7 A194 Gr.7
-46° to -30°C ASTM A350Gr.LF2 A320 Gr.L7 A194 Gr.7
-29° to 427°C ASTM A105 A193 Gr.B7 A194 Gr.2H
428° to 537°C ASTM A182Gr.F11, F22 A193 Gr.B16 A194 Gr.2H
538° to 648°C ASTM A182Gr.F11, F22 A193 Gr.B8 Class1 A194 Gr.8A
649° to 815°C ASTM A182Gr. F304H, F316H A193 Gr.B8 Class1 A194 Gr.8A

Jual Stud Bolt ASTM A193 GR B7 NUT ASTM A194 GR 2H Fluorocarbon Coating

Jual Stud Bolt Coating Fluorocarbon
Fluorocarbon Coating (PTFE, Xylan, Teflon, Emralon ) Lapisan Fluorocarbon adalah lapisan organik yang terdiri dari pelumas padat yang terdispersi dalam pengikat organik dan dilarutkan dalam campuran pelarut yang diformulasikan secara khusus. Hal ini juga tahan korosi karena penggunaan bahan pengikat sintetis thermosetting termal yang termal. Bila dioleskan pada substrat tahan pelepasan, kejang dan resah dan berikan ketahanan terhadap korosi.
Manufactur Stud BoltFluorocarbon


Pelapis Fluorocarbon memiliki karakteristik sebagai berikut:
√ Ini adalah lapisan berkilau
√ Memiliki adhesi yang sangat baik
√ Ketebalan lapisan optimum efektif adalah 15-25 mikron
√ Kapasitas bantalan beban: 1000 bar
√ Resistansi korosi: Antara 100 sampai 400 jam semprotan garam (tergantung ketebalannya) sesuai ASTM B117
√ Jangkauan kerja: 200 ° C (kontinyu), semburan pendek 250 ° C

Technical Specifications:
Use Temperatures Working temp. range up to + 260°C
Corrosion Resistance Salt Spray (ASTM B117)up to 3,000 hrs (Nuts not frozen)
Pencil Hardness 5H - 6H (ASTM D3363-92A)
Kinetic Friction Coefficient 0.06 - 0.08
Thickness Nominal 15-25 mikron
Impact 160 in lb (ASTM D2794-93)
Adhesion 5B (ASTM D3359-95)
Elongation 35%-50%
Tensile Strength 4,000 psi
Operating Pressure Up to 100,000 psi



Jual Stud Bolt
Pelapis Fluorocarbon dapat diaplikasikan dengan cara dip, semprot atau salah satu metode lukisan konvensional. Persiapan permukaan sebelumnya memiliki kaitan dengan kualitas Pelapis Fluorocarbon. Pelapis Fluorocarbon dapat diberikan pada permukaan logam atau paduan apapun, yang dapat diobati dengan tepat, dengan fosfat, peledakan, anodisasi atau Soft Nitriding / Nitrocarburising. Keunggulan Pelapis Fluorocarbon bekerja dengan baik di bawah sejumlah kondisi lingkungan yang ekstrem. Kemampuan pelumasnya dari suhu kamar hingga 200 ° C di udara dan suhu yang lebih tinggi di atmosfer yang tidak mengoksidasi membuatnya menarik untuk aplikasi ruang angkasa. Pelapis Fluorocarbon diberikan pada bagian-bagian mesin yang terkena korosi dan diperlukan pelumasan.

STUD BOLT TYPE :
Ferristic Steel Chromium Molybdenum and Low Allow Steel:
ASTM A193 GR B7 / ASTM A 194 GR 2H
ASTM A193 GR B7M / ASTM A 194 GR 2HM
ASTM A193 GR B16 / ASTM A 194 GR 4
ASTM A320 GR L7/ASTM A194 GR 8

Austenitic Stainless Steel:
ASTM A193 GR B8/ ASTM A194 GR8
ASTM 193 GR B8M/ ASTM A194 GR 8M
Kami juga menerima Stud bolt Finish Coating :
Electrodeposited coating Of cadmium
Electrodeposited coating Of Zinc
Electrodeposited coating Of Zinc chromate
Fluorocarbon coating
Hot Div Galvanize coating

SPIRAL WOUND GASKET INDONESIA

Kami Menjual Dan Memproduksi Gasket
Tersedia Model :
CGI ( Innering Dan Outering )
CG  ( Outering Gasket )
RIR ( Innering Gasket )
R     ( Basic Gasket )
Ring Material :
Carbonn Steel, Stainless Steel
Hoop Standard :
SS304 / SS316
Filler Material :
Graphite / Teflon
Standard :
ANSI #150 - 2500 / JIS #5K - 40 / PN #10 - 40
SPIRAL WOUND GASKET INDONESIA


Standard: ASME B 16.20,API 601
Spiral wound gaskets type
NO. type Thickess(mm) Thickess F (mm)
1 Basic Form 3.2 4.5
2 With inner ring 3.2 4.5
3 With outer ring 3.2 4.5
4 With inner ring and out ring 3.2 4.5


Structure type
Filler Hoop IR OR
Asbestos SUS 304 CS CS
Graphite SUS 316 SUS 304 SUS 304
PTFE SUS 316L SUS 316 SUS 316


The table below may be used for selected material of inner ring and winding metal.
Trade Name AISI Hardness(HB/HV) °C
304 Stainless steel 304 130-180 -220~+550
316 Stainless steel 316 130-180 -100~+550
316L Stainless steel 316L 130-190 -100~+550


The outer ring is generally manufactured from carbon steel with an anti-corronsion treatment.
The table below may be used for determining the correct filler.
Filler °C Max Operating Pressure(Kg/cm2)
304 Stainless steel -200~+550 250
316 Stainless steel -150~+450 100
316L Stainless steel -240~+260 100

JUAL GASKET FLANGE JIS 10K 20K 40K

JUAL GASKET FLANGE JIS 10K 20K 40K

Info Spiral Wound Gasket Call Marketing :
Jual Spiral Wound Gasket ANSI #150 - 2500
Jual Spiral Wound Gasket JIS #5K - 40
Jual Spiral Wound Gasket PN #10 - 40
JUAL GASKET FLANGE JIS 10K 20K 40K
Gasket Flange Jis 10K
Bahan Material :
Carbon Steel, Stainless Steel, Teflon, Rubber, Asbes, Etc

Standard: ASME B 16.20,API 601

Spiral wound gaskets type
NO. type Thickess(mm) Thickess F (mm)
1 Basic Form 3.2 4.5
2 With inner ring 3.2 4.5
3 With outer ring 3.2 4.5
4 With inner ring and out ring 3.2 4.5


Structure type
Filler Hoop IR OR
Asbestos SUS 304 CS CS
Graphite SUS 316 SUS 304 SUS 304
PTFE SUS 316L SUS 316 SUS 316


The table below may be used for selected material of inner ring and winding metal.
Trade Name AISI Hardness(HB/HV) °C
304 Stainless steel 304 130-180 -220~+550
316 Stainless steel 316 130-180 -100~+550
316L Stainless steel 316L 130-190 -100~+550


The outer ring is generally manufactured from carbon steel with an anti-corronsion treatment.
The table below may be used for determining the correct filler.
Filler °C Max Operating Pressure(Kg/cm2)
304 Stainless steel -200~+550 250
316 Stainless steel -150~+450 100
316L Stainless steel -240~+260 100

Jual gasket murah, agen gasket murah, stockis gasket jakarta, distibutor gasket jakarta, supplier gasket murah jakarta

JUAL HEX PLUG GALVANIS A197

JUAL HEX PLUG GALVANIS A197
KAMI MENJUAL DAN SUPPLY HEX PLUG UNTUK MENUTUP LUBANG PIPA ATAU MESIN, TERSEDIA CLASS #150 ASTM A197.
KAMI SIAP MEMBANTU DAN BEKERJA SAMA MENSUPPLY MATERIAL UNTUK MENUNJANG PEKERJAAN ANDA, KAMI JUGA MENERIMA PESANAN PENGIRIMAN MATERIAL KE LUAR DAERAH.
UNTUK HARGA HEX PLUG GALVANIS UKURAN 1/2", 3/4", 1" DAN UKURAN LAINNYA, BISA HUBUNGI MARKETING

JUAL HEX PLUG GALVANIS A197
JUAL HEX PLUG GALVANIS A197
SIZEHARGA
1/2"Call Up
3/4"Call Up
1"Call Up
1-1/4"Call Up
1-1/2"Call Up
2"Call Up
2-1/2"Call Up
3"Call Up
4"Call Up

JUAL HEX PLUG GALVANIS A197, JUAL WATER MUR GALVANIS A197, JUAL DOUBLE NIPPLE GALVANIS ASTM A197, HARGA DOUBLE NIPPLE GALVANIS ASTM A197, JUAL VLOK RING GALVANIS ASTM A197, JUAL KNEE ELBOW ASTM A197 GALVANIS, JUAL TEE A197 GALVANIS, JUAL REDUCER A197 GALVANIS, JUAL WATER MOOR A197 GALVANIS, JUAL SOKET A197 GALVANIS, JUAL NIPPLE A197 GALVANIS,JUAL REDUCER A197 GALVANIS, JUAL BUSING A197 GALVANIS.

All the items we sell at competitive rates,
and our customers a lot of big cities in Indonesia
If in doubt, we can provide our customers on where you are!

Please contact our marketing for more details ( Klik )

JUAL REDUCER GALVANIS A197

JUAL REDUCER GALVANIS A197
KAMI MENJUAL DAN SUPPLY REDUCER UNTUK PENYAMBUNG PIPA YANG BEDA UKURAN, TERSEDIA CLASS #150 ASTM A197.
KAMI SIAP MEMBANTU DAN BEKERJA SAMA MENSUPPLY MATERIAL UNTUK MENUNJANG PEKERJAAN ANDA, KAMI JUGA MENERIMA PESANAN PENGIRIMAN MATERIAL KE LUAR DAERAH.
UNTUK HARGA REDUCER GALVANIS UKURAN 1/2", 3/4", 1" DAN UKURAN LAINNYA, BISA HUBUNGI MARKETING

JUAL CAP GALVANIS DRAT A197
JUAL REDUCER GALVANIS A197
SIZEHARGA
1/2"Call Up
3/4"Call Up
1"Call Up
1-1/4"Call Up
1-1/2"Call Up
2"Call Up
2-1/2"Call Up
3"Call Up
4"Call Up

JUAL REDUCER GALVANIS A197, JUAL WATER MUR GALVANIS A197, JUAL DOUBLE NIPPLE GALVANIS ASTM A197, HARGA DOUBLE NIPPLE GALVANIS ASTM A197, JUAL VLOK RING GALVANIS ASTM A197, JUAL KNEE ELBOW ASTM A197 GALVANIS, JUAL TEE A197 GALVANIS, JUAL REDUCER A197 GALVANIS, JUAL WATER MOOR A197 GALVANIS, JUAL SOKET A197 GALVANIS, JUAL NIPPLE A197 GALVANIS,JUAL REDUCER A197 GALVANIS, JUAL BUSING A197 GALVANIS.

All the items we sell at competitive rates,
and our customers a lot of big cities in Indonesia
If in doubt, we can provide our customers on where you are!

Please contact our marketing for more details ( Klik )

JUAL CAP GALVANIS DRAT A197

JUAL CAP GALVANIS DRAT A197
KAMI MENJUAL DAN SUPPLY CAP UNTUK PENUTUP PIPA CLASS #150 ASTM A197.
KAMI SIAP MEMBANTU DAN BEKERJA SAMA MENSUPPLY MATERIAL UNTUK MENUNJANG PEKERJAAN ANDA, KAMI JUGA MENERIMA PESANAN PENGIRIMAN MATERIAL KE LUAR DAERAH.
UNTUK HARGA CAP GALVANIS UKURAN 1/2", 3/4", 1" DAN UKURAN LAINNYA, BISA HUBUNGI MARKETING


JUAL CAP GALVANIS DRAT A197
JUAL CAP GALVANIS DRAT A197
SIZEHARGA
1/2"Call Up
3/4"Call Up
1"Call Up
1-1/4"Call Up
1-1/2"Call Up
2"Call Up
2-1/2"Call Up
3"Call Up
4"Call Up

JUAL CAP A197 GALVANIS,JUAL WATER MUR GALVANIS A197, JUAL DOUBLE NIPPLE GALVANIS ASTM A197, HARGA DOUBLE NIPPLE GALVANIS ASTM A197, JUAL VLOK RING GALVANIS ASTM A197, JUAL KNEE ELBOW ASTM A197 GALVANIS, JUAL TEE A197 GALVANIS, JUAL REDUCER A197 GALVANIS, JUAL WATER MOOR A197 GALVANIS, JUAL SOKET A197 GALVANIS, JUAL NIPPLE A197 GALVANIS,JUAL REDUCER A197 GALVANIS, JUAL BUSING A197 GALVANIS.

All the items we sell at competitive rates,
and our customers a lot of big cities in Indonesia
If in doubt, we can provide our customers on where you are!

Please contact our marketing for more details ( Klik )

JUAL SOCKET DRAT GALVANIS A197

JUAL SOCKET DRAT GALVANIS A197
KAMI MENJUAL DAN SUPPLY WATER MUR CLASS #150 ASTM A197.
KAMI SIAP MEMBANTU DAN BEKERJA SAMA MENSUPPLY MATERIAL UNTUK MENUNJANG PEKERJAAN ANDA, KAMI JUGA MENERIMA PESANAN PENGIRIMAN MATERIAL KE LUAR DAERAH.
UNTUK HARGA SOCKET DRAT GALVANIS UKURAN 1/2", 3/4", 1" DAN UKURAN LAINNYA, BISA HUBUNGI MARKETING


JUAL SOCKET DRAT A197 GALVANIS
JUAL SOCKET DRAT GALVANIS A197
SIZEHARGA
1/2"Call Up
3/4"Call Up
1"Call Up
1-1/4"Call Up
1-1/2"Call Up
2"Call Up
2-1/2"Call Up
3"Call Up
4"Call Up

JUAL WATER MUR GALVANIS A197, JUAL DOUBLE NIPPLE GALVANIS ASTM A197, HARGA DOUBLE NIPPLE GALVANIS ASTM A197, JUAL VLOK RING GALVANIS ASTM A197, JUAL KNEE ELBOW ASTM A197 GALVANIS, JUAL TEE A197 GALVANIS, JUAL REDUCER A197 GALVANIS,JUAL CAP A197 GALVANIS, JUAL WATER MOOR A197 GALVANIS, JUAL SOKET A197 GALVANIS, JUAL NIPPLE A197 GALVANIS,JUAL REDUCER A197 GALVANIS, JUAL BUSING A197 GALVANIS.

All the items we sell at competitive rates,
and our customers a lot of big cities in Indonesia
If in doubt, we can provide our customers on where you are!

Please contact our marketing for more details ( Klik )

JUAL WATER MUR GALVANIS A197

JUAL WATER MUR GALVANIS A197
KAMI MENJUAL DAN SUPPLY WATER MUR CLASS #150 ASTM A197.
KAMI SIAP MEMBANTU DAN BEKERJA SAMA MENSUPPLY MATERIAL UNTUK MENUNJANG PEKERJAAN ANDA, KAMI JUGA MENERIMA PESANAN PENGIRIMAN MATERIAL KE LUAR DAERAH.
UNTUK HARGA WATER MUR GALVANIS 1/2", 3/4", 1" DAN UKURAN LAINNYA, BISA HUBUNGI MARKETING


JUAL WATER MUR A197 GALVANIS
JUAL WATER MUR GALVANIS A197
SIZEHARGA
1/2"Call Up
3/4"Call Up
1"Call Up
1-1/4"Call Up
1-1/2"Call Up
2"Call Up
2-1/2"Call Up
3"Call Up
4"Call Up

JUAL WATER MUR GALVANIS A197, JUAL DOUBLE NIPPLE GALVANIS ASTM A197, HARGA DOUBLE NIPPLE GALVANIS ASTM A197, JUAL VLOK RING GALVANIS ASTM A197, JUAL KNEE ELBOW ASTM A197 GALVANIS, JUAL TEE A197 GALVANIS, JUAL REDUCER A197 GALVANIS,JUAL CAP A197 GALVANIS, JUAL WATER MOOR A197 GALVANIS, JUAL SOKET A197 GALVANIS, JUAL NIPPLE A197 GALVANIS,JUAL REDUCER A197 GALVANIS, JUAL BUSING A197 GALVANIS.

All the items we sell at competitive rates,
and our customers a lot of big cities in Indonesia
If in doubt, we can provide our customers on where you are!

Please contact our marketing for more details ( Klik )

JUAL DOUBLE NIPPLE GALVANIS ASTM A197

JUAL DOUBLE NIPPLE GALVANIS ASTM A197
KAMI MENJUAL DAN SUPPLY DOUBLE NIPPLE CLASS #150 ASTM A197.
KAMI SIAP MEMBANTU DAN BEKERJA SAMA MENSUPPLY MATERIAL UNTUK MENUNJANG PEKERJAAN ANDA, KAMI JUGA MENERIMA PESANAN PENGIRIMAN MATERIAL KE LUAR DAERAH.
UNTUK HARGA DOUBLE NIPPLE GALVANIS 1/2", 3/4", 1" DAN UKURAN LAINNYA, BISA HUBUNGI MARKETING

JUAL DOUBLE NIPPLE A197 GALVANIS
JUAL DOUBLE NIPPLE GALVANIS
SIZEHARGA
1/2"Call Up
3/4"Call Up
1"Call Up
1-1/4"Call Up
1-1/2"Call Up
2"Call Up
2-1/2"Call Up
3"Call Up
4"Call Up

JUAL DOUBLE NIPPLE GALVANIS ASTM A197, HARGA DOUBLE NIPPLE GALVANIS ASTM A197, JUAL VLOK RING GALVANIS ASTM A197, JUAL KNEE ELBOW ASTM A197 GALVANIS, JUAL TEE A197 GALVANIS, JUAL REDUCER A197 GALVANIS,JUAL CAP A197 GALVANIS, JUAL WATER MOOR A197 GALVANIS, JUAL SOKET A197 GALVANIS, JUAL NIPPLE A197 GALVANIS,JUAL REDUCER A197 GALVANIS, JUAL BUSING A197 GALVANIS.

All the items we sell at competitive rates,
and our customers a lot of big cities in Indonesia
If in doubt, we can provide our customers on where you are!

Please contact our marketing for more details ( Klik )

JUAL VLOK RING GALVANIS ASTM A197

JUAL VLOK RING GALVANIS ASTM A197
KAMI MENJUAL DAN SUPPLY KNEE ATAU ELBOW CLASS #150 ASTM A197.
KAMI SIAP MEMBANTU DAN BEKERJA SAMA MENSUPPLY MATERIAL UNTUK MENUNJANG PEKERJAAN ANDA, KAMI JUGA MENERIMA PESANAN PENGIRIMAN MATERIAL KE LUAR DAERAH.
UNTUK HARGA VLOK RING GALVANIS 1/2", 3/4", 1" DAN UKURAN LAINNYA, BISA HUBUNGI MARKETING

JUAL VLOK RING A197 GALVANIS
JUAL VLOK RING GALVANIS ASTM A197
SIZEHARGA
1/2"Call Up
3/4"Call Up
1"Call Up
1-1/4"Call Up
1-1/2"Call Up
2"Call Up
2-1/2"Call Up
3"Call Up
4"Call Up

JUAL VLOK RING GALVANIS ASTM A197, JUAL KNEE ELBOW ASTM A197 GALVANIS, JUAL TEE A197 GALVANIS, JUAL REDUCER A197 GALVANIS,JUAL CAP A197 GALVANIS, JUAL WATER MOOR A197 GALVANIS, JUAL SOKET A197 GALVANIS, JUAL NIPPLE A197 GALVANIS,JUAL REDUCER A197 GALVANIS, JUAL BUSING A197 GALVANIS.

All the items we sell at competitive rates,
and our customers a lot of big cities in Indonesia
If in doubt, we can provide our customers on where you are!

Please contact our marketing for more details ( Klik )

JUAL TEE DRAT GALVANIS A197

JUAL TEE ASTM A197 GALVANIS
KAMI MENJUAL DAN SUPPLY KNEE ATAU ELBOW CLASS #150 ASTM A197.
KAMI SIAP MEMBANTU DAN BEKERJA SAMA MENSUPPLY MATERIAL UNTUK MENUNJANG PEKERJAAN ANDA, KAMI JUGA MENERIMA PESANAN PENGIRIMAN MATERIAL KE LUAR DAERAH.
UNTUK HARGA TEE GALVANIS 1/2", 3/4", 1" DAN UKURAN LAINNYA, BISA HUBUNGI MARKETING


JUAL TEE A197 GALVANIS
JUAL TEE DRAT GALVANIS A197
SIZEHARGA
1/2"Call Up
3/4"Call Up
1"Call Up
1-1/4"Call Up
1-1/2"Call Up
2"Call Up
2-1/2"Call Up
3"Call Up
4"Call Up

JUAL KNEE ELBOW ASTM A197 GALVANIS, JUAL TEE A197 GALVANIS, JUAL REDUCER A197 GALVANIS,JUAL CAP A197 GALVANIS, JUAL WATER MOOR A197 GALVANIS, JUAL SOKET A197 GALVANIS, JUAL NIPPLE A197 GALVANIS,JUAL REDUCER A197 GALVANIS, JUAL BUSING A197 GALVANIS.

All the items we sell at competitive rates,
and our customers a lot of big cities in Indonesia
If in doubt, we can provide our customers on where you are!

Please contact our marketing for more details ( Klik )

JUAL KNEE ELBOW ASTM A197 GALVANIS

JUAL KNEE ELBOW ASTM A197 GALVANIS
KAMI MENJUAL DAN SUPPLY KNEE ATAU ELBOW CLASS #150 ASTM A197.
KAMI SIAP MEMBANTU DAN BEKERJA SAMA MENSUPPLY MATERIAL UNTUK MENUNJANG PEKERJAAN ANDA, KAMI JUGA MENERIMA PESANAN PENGIRIMAN MATERIAL KE LUAR DAERAH.
UNTUK HARGA KNEE GALVANIS 1/2", 3/4", 1" DAN UKURAN LAINNYA, BISA HUBUNGI MARKETING

JUAL KNEE 90⁰ A197 GALVANIS
JUAL ELBOW A197 GALVANIS
SIZEHARGA
1/2"3.450,-
3/4"Call Up
1"Call Up
1-1/4"Call Up
1-1/2"Call Up
2"Call Up
2-1/2"Call Up
3"Call Up
4"Call Up

JUAL KNEE ELBOW ASTM A197 GALVANIS, JUAL TEE A197 GALVANIS, JUAL REDUCER A197 GALVANIS,JUAL CAP A197 GALVANIS, JUAL WATER MOOR A197 GALVANIS, JUAL SOKET A197 GALVANIS, JUAL NIPPLE A197 GALVANIS,JUAL REDUCER A197 GALVANIS, JUAL BUSING A197 GALVANIS.

All the items we sell at competitive rates,
and our customers a lot of big cities in Indonesia
If in doubt, we can provide our customers on where you are!

Please contact our marketing for more details ( Klik )

JUAL SEAL TAPE MURAH MERK HQ

Jual seal tape 100% PTFE TEFLON tersedia merk HQ dan Onda
JUAL SEAL TAPE MURAH
Seal Tape HQ
SIZE : 12mm X 0.075mm X 10 Meter
Cocok untuk kran, Gate Valve, Ball, Water meter, Sambungan Pvc Dll

TABEL BERAT COUPLING CLASS 3000 CS A105

TABEL BERAT COUPLING CLASS 3000 CS A105

TABEL BERAT COUPLING CLASS 3000 CS A105 SOCKET WELD, TABEL BERAT COUPLING CLASS 3000 CS A105 NPT, TABEL BERAT COUPLING CLASS 6000 CS A105 SOCKET WELD, TABEL BERAT COUPLING CLASS 6000 CS A105 NPT.

Couplings Class 3000 A105 CS
DN SIZE
Couplings Class 3000 Socket weld
Couplings Class 3000 Npt
kg Lb kg Lb
1/2 0,13 0,280 0,13 0,290
3/4 0,17 0,40 0,19 0,42
1 0,29 0,65 0,45 0,83
1 1/4 0,45 1,05 0,81 1,58
1 1/2 0,59 1,23 1,07 2,16
2 0,86 2,05 1,40 2,99
2 1/2 1,40 3,12 2,29 4,75
3 1,78 3,83 3,38 6,51

TABEL BERAT UNION CLASS 3000 A105 CS

TABEL BERAT UNION CLASS 3000 A105 CS

TABEL BERAT UNION CLASS 3000 SOCKET WELD, TABEL BERAT UNION CLASS 3000 NPT, TABEL BERAT UNION CLASS 6000 SOCKET WELD, TABEL BERAT UNION CLASS 6000 NPT.


Union Class 3000 A105 CS
DN SIZE
BERAT UNION CLASS 3000 SOCKET WELD
BERAT UNION CLASS 3000 DRAT
kg Lb kg Lb
1/2 0,13 0,730 0,34 0,730
3/4 0,49 1,19 0,48 1,19
1 0,81 1,66 0,77 1,66
1 1/4 1,10 2,66 1,03 2,66
1 1/2 1,61 3,42 1,63 3,42
2 2,16 5,36 2,43 5,36
2 1/2 3,50 9,12 3,63 9,12
3 5,15 12,58 5,27 12,58

TABEL BERAT TEE CLASS 3000 CARBON STEEL

TABEL BERAT TEE CLASS 3000 DAN 6000 NPT
JUAL FORGED FITTING TEE CLASS 3000, JUAL TEE FITING BOTHWELL INDONESIA,TABEL BERAT TEE CLASS 3000 SOKET WELD, TABEL BERAT TEE CLASS 3000 DRAT, TABEL BERAT TEE CLASS 6000 SOKET, TABEL BERAT TEE CLASS 6000 NPT

TEE CLASS 3000 CARBON STEEL A105
DN SIZE
TABEL BERAT TEE CLASS 3000
TABEL BERAT TEE CLASS 3000
kg Lb kg Lb
1/2 0,29 0,620 0,56 1,200
3/4 0,42 0,88 0,92 1,87
1 0,65 1,30 1,49 2,95
1 1/4 1,04 2,00 1,76 3,92
1 1/2 1,35 2,99 3,27 7,35
2 2,04 4,60 3,53 7,58
2 1/2 3,98 8,49 6,99 14,61
3 5,90 13,85 10,19 22,82

TABEL BERAT ELBOW CLASS 3000

TABEL BERAT ELBOW CLASS 3000 DAN 6000 NPT
JUAL FORGED FITTING CLASS 3000, JUAL FITING BOTHWELL INDONESIA,TABEL BERAT ELBOW CLASS 3000 SOKET WELD, TABEL BERAT ELBOW CLASS 3000 DRAT, TABEL BERAT ELBOW CLASS 6000 SOKET, TABEL BERAT ELBOW CLASS 6000 NPT.

ELBOW CLASS 3000 (Threaded)
DN SIZE TABEL BERAT ELBOW TABEL BERAT ELBOW 45D
kg Lb kg Lb
1/2 0,43 0,92 0,34 0,76
3/4 0,69 1,47 0,56 1,23
1 1,14 2,33 0,94 1,87
1 1/4 1,42 2,98 1,03 2,29
1 1/2 2,63 5,72 2,05 4,60
2 2,92 6,53 2,23 5,50
2 1/2 5,99 11,03 3,71 7,84
3 8,88 18,83 5,97 13,52


TABEL BERAT ELBOW CLASS 3000 DAN 6000 SW
ELBOW CLASS 3000 (Socket Weld)
DN SIZE
TABEL BERAT ELBOW CLASS 3000 SW
TABEL BERAT ELBOW CLASS 3000 SW
kg Lb kg Lb
1/2 0,22 0,482 0,20 0,401
3/4 0,33 0,68 0,28 0,55
1 0,53 1,06 0,42 0,89
1 1/4 0,84 1,72 0,69 1,23
1 1/2 1,08 2,33 0,80 1,76
2 1,68 3,88 1,35 3,02
2 1/2 3,20 7,34 2,53 7,62
3 5,38 11,61 5,10 12,49

HARGA EXPANSION JOINT RUBBER

Harga Flexible rubber Tozen, Harga Flexible rubber gala, Harga Flexible rubber afaflex, Harga Flexible rubber muraflex, Harga Flexible rubber armflex.

HARGA EXPANSION JOINT RUBBER
Expansion Joint Rubber
Typical Application
Operating Conditions
Size Range 1-1/4" to 6" 8" to 12"
Max. Pressure* 285 psig 228 psig
Oper. Temperature 14° to 158°F
Vacuum Rating* 25" Hg
rst Pressure* Greater than 780 psig
* at normal temperature of 80°F

Material of Construction
Item Component Material
1 Flange ss400/fcd450
2 Reinforcing Ring Carbona steel(SWRH)
3 Inner Rubber Synthetic Rubber
4 Outer Rubber Synthetic Rubber
5 Reinfocing Cord Synthetic Fiber
Dimension and Allowable movements
Pipe Size Length (L) Model No. Allowable Movements* Weight & Carton Box Size
T.M. A.E. A.C. A.M.
1-1/4 " 7 " TWF114M 3/4" 3/8" 3/4" 30° 7.3 lbs & 0.29 ft3
1-1/2 " 7 " TWF112M 3/4" 3/8" 3/4" 30° 8.4 lbs & 0.35 ft3
2" 7 " TWF2M 3/4" 3/8" 3/4" 30° 9.7 lbs & 0.40 ft3
2-1/2 " 7 " TWF212M 3/4" 3/8" 3/4" 30° 12.2 lbs & 0.46 ft3
3 " 7 " TWF3M 3/4" 3/8" 3/4" 30° 13.3 lbs & 0.53 ft3
4 " 9 " TWF4M 1 5/8" 1-1/4" 30° 17.0 lbs & 0.87 ft3
5 " 9 " TWF5M 1 5/8" 1-1/4" 30° 25.4 lbs & 1.15 ft3
6 " 9 " TWF6M 1 5/8" 1-1/4" 30° 32.9 lbs & 1.45 ft3
8 " 13 " TWF8M 1-1/4" 3/5" 1-1/4" 30° 43.7 lbs & 2.65 ft3
10 " 13 " TWF10M 1-1/4" 3/5" 1-1/4" 30° 67.9 lbs & 4.05 ft3
12 " 13 " TWF12M 1-1/4" 3/4" 1-1/4" 30° 82.7 lbs & 5.60 ft3
* Information in the above table is for single movement only.
In case of complex movements, some correction is required as follows.
C.EL(C) =A.EL(C)X{1-( T.M./A.T.M. + A.M. /A.A.M. )}
T.M. = Transverse Movement,
A.E. = Axial Elongation,
A.C. = Axial Compression,
A.M. = Angular Movement.
C.EL(C) = Correct Elongation (Compression)
A.EL(C) = Allowable Elongation (Compression)
A.T.M. = Allowable Transverse Movement
A.A.M. = Allowable Angular Movement Install the joint according to the above given allowable dimensions.

TABEL BERAT FITTING CLASS 2000-3000-6000 SW DAN NPT

TABEL BERAT ELBOW CLASS 2000-3000-6000 SW DAN NPT,  TABEL BERAT TEE CLASS 2000-3000-6000 SW DAN NPT,  TABEL BERAT CAP CLASS 2000-3000-6000 SW DAN NPT,  TABEL BERAT COUPLING CLASS 2000-3000-6000 SW DAN NPT,  TABEL BERAT UNION CLASS 2000-3000-6000 SW DAN NPT,  TABEL BERAT HEX PLUG CLASS 2000-3000-6000 SW DAN NPT.


TABEL BERAT FITTING CLASS 2000-3000-6000 SW DAN NPT
Tabel berat fitting
DOWNLOAD BERAT FITTING CLASS 300 PDF   KLIK


DOWNLOAD CATALOG BERAT FITTING CARBON STEEL ASTM A234 WPB :


DOWNLOAD CATALOG BERAT ELBOW 45D A234 WPB
DOWNLOAD CATALOG BERAT ELBOW 90D A234 WPB
DOWNLOAD CATALOG BERAT ELBOW 180D A234 WPB
DOWNLOAD CATALOG BERAT TEE A234 WPB
DOWNLOAD CATALOG BERAT REDUCER A234 WPB
DOWNLOAD CATALOG BERAT CAP A234 WPB

TABEL BERAT FLANGE JIS 5K 10K 16K 20K

Tabel Berat flange besi jis 5k, Tabel Berat flange besi jis 10k, Tabel Berat flange besi jis 16k, Tabel Berat flange besi jis 20k, Tabel Berat flange besi jis 40k.

Tabel Berat flange besi PN10, Tabel Berat flange besi PN16, Tabel Berat flange besi PN25, Tabel Berat flange besi PN40.

Tabel Berat flange besi ansi 150, Tabel Berat flange besi ansi 300, Tabel Berat flange besi ansi 600, Tabel Berat flange besi ansi 900, Tabel Berat flange besi ansi1500, Tabel Berat flange besi ansi 2500.


TABEL BERAT FLANGE JIS 5K 10K 16K 20K
Download berat flange jis Klik

Tabel Berat Flange Besi Class 150 -2500# Lengkap Klik
Tabel Berat Flange Besi Buta PN.6 - PN40 Lengkap Klik
Tabel Berat Flange Besi Soff PN6- PN40 Lengkap Klik
Tabel Berat Flange Besi Jis 5K - 20K Lengkap Klik

FLANGE SLIP ON A105 ANSI B16.5
DOWNLOAD CATALOG FLANGE SLIP ON A105 ANSI B16.5 CLASS 150
DOWNLOAD CATALOG FLANGE SLIP ON A105 ANSI B16.5 CLASS 300
DOWNLOAD CATALOG FLANGE SLIP ON A105 ANSI B16.5 CLASS 400
DOWNLOAD CATALOG FLANGE SLIP ON A105 ANSI B16.5 CLASS 600
DOWNLOAD CATALOG FLANGE SLIP ON A105 ANSI B16.5 CLASS 800
DOWNLOAD CATALOG FLANGE SLIP ON A105 ANSI B16.5 CLASS 1500

FLANGE WELDING NECK A105 ANSI B16.5
DOWNLOAD CATALOG FLANGE WELDING NECK A105 ANSI B16.5 CLASS 150
DOWNLOAD CATALOG FLANGE WELDING NECK A105 ANSI B16.5 CLASS 300
DOWNLOAD CATALOG FLANGE WELDING NECK A105 ANSI B16.5 CLASS 400
DOWNLOAD CATALOG FLANGE WELDING NECK A105 ANSI B16.5 CLASS 600
DOWNLOAD CATALOG FLANGE WELDING NECK A105 ANSI B16.5 CLASS 900
DOWNLOAD CATALOG FLANGE WELDING NECK A105 ANSI B16.5 CLASS 1500
DOWNLOAD CATALOG FLANGE WELDING NECK A105 ANSI B16.5 CLASS 2500

BLIND FLANGE A105 ANSI B16.5
DOWNLOAD CATALOG BLIND FLANGE A105 ANSI B16.5 CLASS 150
DOWNLOAD CATALOG BLIND FLANGE A105 ANSI B16.5 CLASS 300
DOWNLOAD CATALOG BLIND FLANGE A105 ANSI B16.5 CLASS 400
DOWNLOAD CATALOG BLIND FLANGE A105 ANSI B16.5 CLASS 600
DOWNLOAD CATALOG BLIND FLANGE A105 ANSI B16.5 CLASS 900
DOWNLOAD CATALOG BLIND FLANGE A105 ANSI B16.5 CLASS 1500
DOWNLOAD CATALOG BLIND FLANGE A105 ANSI B16.5 CLASS 2500

FLANGE JIS B2220
DOWNLOAD CATALOG FLANGE JIS 5K - 10K
DOWNLOAD CATALOG FLANGE JIS 16K - 20K

DOWNLOAD BERAT FLANGE BESI

Tabel Berat flange besi jis 5k, Tabel Berat flange besi jis 10k, Tabel Berat flange besi jis 16k, Tabel Berat flange besi jis 20k, Tabel Berat flange besi jis 40k,
Tabel Berat flange besi PN10, Tabel Berat flange besi PN16, Tabel Berat flange besi PN25, Tabel Berat flange besi PN40,
Tabel Berat flange besi ansi 150, Tabel Berat flange besi ansi 300, Tabel Berat flange besi ansi 600, Tabel Berat flange besi ansi 900, Tabel Berat flange besi ansi1500, Tabel Berat flange besi ansi 2500,

DOWNLOAD BERAT FLANGE BESI

Tabel Berat Flange Besi Class 150 -2500# Lengkap Klik
Tabel Berat Flange Besi Buta PN.6 - PN40 Lengkap Klik
Tabel Berat Flange Besi Soff PN6- PN40 Lengkap Klik

FLANGE SLIP ON A105 ANSI B16.5
DOWNLOAD CATALOG FLANGE SLIP ON A105 ANSI B16.5 CLASS 150
DOWNLOAD CATALOG FLANGE SLIP ON A105 ANSI B16.5 CLASS 300
DOWNLOAD CATALOG FLANGE SLIP ON A105 ANSI B16.5 CLASS 400
DOWNLOAD CATALOG FLANGE SLIP ON A105 ANSI B16.5 CLASS 600
DOWNLOAD CATALOG FLANGE SLIP ON A105 ANSI B16.5 CLASS 800
DOWNLOAD CATALOG FLANGE SLIP ON A105 ANSI B16.5 CLASS 1500

FLANGE WELDING NECK A105 ANSI B16.5
DOWNLOAD CATALOG FLANGE WELDING NECK A105 ANSI B16.5 CLASS 150
DOWNLOAD CATALOG FLANGE WELDING NECK A105 ANSI B16.5 CLASS 300
DOWNLOAD CATALOG FLANGE WELDING NECK A105 ANSI B16.5 CLASS 400
DOWNLOAD CATALOG FLANGE WELDING NECK A105 ANSI B16.5 CLASS 600
DOWNLOAD CATALOG FLANGE WELDING NECK A105 ANSI B16.5 CLASS 900
DOWNLOAD CATALOG FLANGE WELDING NECK A105 ANSI B16.5 CLASS 1500
DOWNLOAD CATALOG FLANGE WELDING NECK A105 ANSI B16.5 CLASS 2500

BLIND FLANGE A105 ANSI B16.5
DOWNLOAD CATALOG BLIND FLANGE A105 ANSI B16.5 CLASS 150
DOWNLOAD CATALOG BLIND FLANGE A105 ANSI B16.5 CLASS 300
DOWNLOAD CATALOG BLIND FLANGE A105 ANSI B16.5 CLASS 400
DOWNLOAD CATALOG BLIND FLANGE A105 ANSI B16.5 CLASS 600
DOWNLOAD CATALOG BLIND FLANGE A105 ANSI B16.5 CLASS 900
DOWNLOAD CATALOG BLIND FLANGE A105 ANSI B16.5 CLASS 1500
DOWNLOAD CATALOG BLIND FLANGE A105 ANSI B16.5 CLASS 2500

FLANGE JIS B2220
DOWNLOAD CATALOG FLANGE JIS 5K - 10K
DOWNLOAD CATALOG FLANGE JIS 16K - 20K


Jika info ini bermanfa'at silahkan share ke rekan anda agar lebih bermanfa'at
Jangan lupa like FB kami

TABEL BERAT FLANGE BESI DIN - 2527

TABEL BERAT FLANGE DIN - 2527
TABEL BERAT FLANGE BUTA PN.6, TABEL BERAT FLANGE BUTA PN.10, TABEL BERAT FLANGE BUTA PN.16, TABEL BERAT FLANGE BUTA PN.25, TABEL BERAT FLANGE BUTA PN.40, TABEL BERAT FLANGE BUTA PN.64, TABEL BERAT FLANGE BUTA PN.100
TABEL BERAT FLANGE DIN - 2527
BLIND 2527

Nominal Pipe Size BERAT FLANGES DIN - 2527
IN MM PN.6 PN.10 PN.16 PN.25 PN.40 PN.64 PN.100
3/8" 10 0.38 0.63 0.63 0.72 0.72 1.04 1.04
1/2'' 15 0.44 0.71 0.71 0.81 0.81 1.16 1.16
3/4'' 20 0.66 1.01 1.01 1.14 1.14 2.54 2.54
1'' 25 0.82 1.23 1.23 1.38 1.38 3.07 3.07
1.1/4'' 32 1.18 1.81 1.81 2.03 2.03 3.97 3.97
1.1/2'' 40 1.39 2.09 2.09 2.35 2.35 4.51 5.64
2'' 50 1.62 2.88 2.88 3.20 3.20 5.69 7.43
2.1/2'' 65 2.14 3.65 3.65 4.29 4.29 6.88 8.84
3'' 80 3.43 4.61 4.61 5.54 5.54 9.99 13.31
4'' 100 4.22 5.65 5.65 7.60 7.60 15.91 21.30
5'' 125 6.10 8.13 8.13 10.82 10.82 23.32 29.43
6'' 150 7.51 10.49 10.49 14.60 14.60 30.35 38.75
8'' 175 10.41 14.11 14.11 17.40 22.04 39.17 52.66
10'' 200 12.31 16.53 16.26 22.47 27.21 56.64 85.41
12'' 250 18.55 24.08 24.99 33.51 44.38 81.14 128.05
14'' 300 25.47 30.81 35.13 46.29 64.17 112.95 174.53
16'' 350 31.78 39.64 48.01 68.08 89.52 152.30 -
18'' 400 38.50 49.44 83.53 89.59 126.76 - -
20'' 500 60.13 75.16 108.63 140.66 184.63 - -
24'' 600 96.07 109.20 136.47 202.30 285.17 - -
28'' 700 133.80 153.77 189.87 271.05 368.83 - -
32'' 800 183.29 222.86 269.57 373.52 528.39 - -
36'' 900 251.70 299.08 355.31 479.07 690.99 - -
40'' 1000 350.98 418.78 469.20 632.47 912.42 - -
